Product features
- Gigabit 2.5G Single Power Port Ethernet Adapter RJ45 Interface
- Innovative power management features and Energy Efficient Ethernet (EEE).
- Integrated Direct Memory Improves Efficiency and Reduces Power Consumption
- High-performance host interface design
- Reliable solution proves server adapter's excellent performance
- Compatible with a wide range of domestic and international systems and devices
Key attributes
Model Number: W2.5G-TR-V1.0
Brand Name:GRT
Warranty Time:3 years
Certification:FCC, RoHS, CE
Data rate:2.5GbE network card
Ethernet controller:RTL8125
Application:Servers, GAP, Firewall, storage device,etc.
|
Specification |
Description |
|
Product Code |
W2.5G-TR-V1.0 |
|
Ethernet Controller |
RTL8125 |
|
Port |
Single Port |
|
Interface Speed |
10M/100M/1000M/2.5G |
|
Connector |
RJ-45 Interface |
|
Supported Slot Height |
Half and Full Height |
|
Operating Temperature |
0°C - 55°C |
|
Operating Humidity |
0% - 90% non-condensing |
|
LED Indicator |
2.5G: rate upper light green constant, lower light green blinking |
|
Power Rating |
Gigabit: upper light orange constant, lower light green blinking |
|
Speed and slot width |
Hundred megabit: upper light is orange, lower light is blinking light green |
|
Physical Specifications |
Description |
|
Length |
65.29mm |
|
Width |
55.39mm |
|
Full-height stopper |
121.04mm |
|
Half-High Block |
80.22mm |
|
PCIE Specification |
X1 |
|
OSystem |
Supported Systems |
|
Platforms |
Supported corresponding systems |
|
X86 Platform |
Linux 7.0-8.0 |
|
X86 Platform |
Windows 10, Windows 11, etc. |
|
X86 Platform |
2012 R2, 2016, 2019, 2022 |
|
X86 Platform |
RedHat 6.6~7.4 |
|
X86 Platform |
Ubuntu 14.04/16.10 |
|
X86 Platform |
Linux SLES 11(SP3) |
|
X86 Platform |
Linux SLES 12(sp1) |
|
SUNWAY |
deepin |
|
Kun Peng |
NeoKylin |
|
Loongson |
NeoKylin |
|
Phytuum |
Fetion |
|
HYGON |
UOS |
|
ARM |
Kirin System |
Product Description
W2.5G-TR-V1.0 RTL8125 Ethernet adapter is based on the localized chip solution of Guanghe Zhida Technology (Beijing) Co., Ltd. and adopts the RTL8125 Ethernet controller, which is often used in servers, firewalls, network gates and other high-end equipment.
The adapter is designed to optimize performance so that system I/O is no longer a bottleneck in high-end network applications. The adapter is fault tolerant through bundled groups, where traffic from a failed port is routed to other members of the group. The adapter is an ideal solution for deploying multiple networks and for deploying critical network applications and environments on high-performance servers.
This server adapter represents a new step in the evolution of Gigabit 2.5G networking for enterprises and data centers. It takes performance to the next level with industry-leading enhancements for the Internet Small Computer System Interface Unified Networking environment. This new adapter series also integrates new power management technologies, stable power solutions and more.
Compatibility
All of GRT's products are open sourced, fully compatible with major brands' products and devices, such as Intel, Dell, Cisco, Finisar, Arista, HP, Mellanox, Juniper, HUAWEI, H3C, etc.
For other brands' devices, please specify when ordering so that we can write corresponding codes for your easy application.
Packing & Shipping
Packed in blister box and paper box, 1piece/box. Normal orders to be shipped within 2 working days upon receipt of payment.
We can ship by TNT, FedEx, EMS, UPS, DHL, or other named forwarders as per your request.
